How to create a context filter

This document will show you how to create a context filter. A context filter decides when something applies - for example, a modifier set that only prompts on Dine-In orders, or a comp that only shows at one location.

How to Build a context filter

  1. Backoffice --> POS --> Settings --> Context Filters --> Click New Context Filter

Backoffice with POS, Settings and Context Filters marked, and the New Context Filter button circled

  1. Fill out the context filter. The numbers match the picture:

A new context filter named Dine-In Only, with numbers on the name, description, rule name, strategy, session filters, order types, guest count and Add Rule

  1. Name (required): Name it something short and recognizable
  2. Description: Use the description to add more details about what this filter will do
  3. Rule Name (required): Every filter has at least one rule, named "Default" to start. Give it a name that says what it checks, especially if you plan on having more than 1 rule in this filter
  4. Strategy: Use the strategy to decide if the filter is going to include or exclude what you select below
    1. Include if Any - At least one selection below will need to be true for this filter to be valid
    2. Include if All - ALL selections below will need to be true for this filter to be valid
    3. Exclude if Any - This filter will be valid unless one of the selections below is true
    4. Exclude if All - This filter will be valid unless ALL of the selections below are true
  5. Session Filters: Where the order is being taken and by whom. You can pick more than one in each list
    • Locations: The stores this filter checks
    • Profit Centers: The profit centers this filter checks
    • Zones: The zones this filter checks
    • Brands: The brands this filter checks
    • Job Roles: The job roles of the employee taking the order
    • Devices: The terminals or handhelds this filter checks
    • Device Types: A kind of device, for example every Handheld or every Terminal
  6. Order Types: Pick the order types this filter checks, such as Dine-In or To-Go
  7. Guest Count From and Guest Count To: Use these to have the filter check how many guests are on the order
  8. Add Rule: If you are having more than 1 rule in this filter, click Add Rule and set up the next rule the same way. The filter is valid when any one of its rules is

Note: Leave a filter empty to ignore it. A rule checks only the filters you fill in.

  1. Click Save
  2. Test the rule



Where you can use a context filter

Many screens in Backoffice have a Context Filter drop-down. To use your filter, open the record, select the filter in that drop-down and click Save. From then on the record only shows or applies when the filter is valid. Leave the drop-down empty and it works everywhere, as before.

The Edit Comp Reason window with the Context Filter drop-down and Save circled

You can use a context filter on:

Items and Modifiers

  • Items (POS --> Items, the item's Details tab): the item only shows on the terminal when the filter is valid
  • Item categories (POS --> Items, click the category): the whole category only shows when the filter is valid
  • A modifier set on an item (the item's Modifiers tab, When To Prompt): the item only asks for that modifier set when the filter is valid
  • Modifier Sets (POS --> Modifiers --> Modifier Sets): the field is called Prompted Context Filter - the set is only asked for when the filter is valid
  • Modifier items in a set (the modifier set's Modifier Items tab): the choice only shows in the set when the filter is valid
  • Sizes (POS --> Settings --> Size Groups): the size is only offered when the filter is valid

Click here to see an example filter be configured so that the alcohol mod set doesn't prompt on a bar device.

Settings

  • Terminal screens (POS --> Settings --> Terminal Setup): a tab or a button on a terminal screen only shows when the filter is valid
  • Price Levels (POS --> Settings --> Price Levels): the price level only applies when the filter is valid
  • Comps and Voids (POS --> Settings --> Comps / Voids): the reason can only be picked when the filter is valid
  • Discounts (POS --> Settings --> Discounts): the discount can only be used when the filter is valid
  • Charges (POS --> Settings --> Charges): a charge or an auto charge only applies when the filter is valid

Gift Cards and Billboards

  • Gift card types (POS --> Gift Cards): the gift card type is only available when the filter is valid
  • Billboards (POS --> Billboards): the billboard only shows when the filter is valid

System Setup

  • Order Types (POS --> System Setup --> Order Types): the order type is only offered when the filter is valid
  • Delivery Zones (POS --> System Setup --> Delivery Zones): the delivery zone only applies when the filter is valid
  • Tenders (POS --> System Setup --> Tenders): the payment type is only available when the filter is valid
  • Auto Print Rules (POS --> System Setup --> Auto Print Rules): the rule only prints when the filter is valid
  • Receipt Setup (POS --> System Setup --> Receipt Setup): a part of the receipt only prints when the filter is valid
  • Ticket Routing Rules (POS --> System Setup --> Kitchen Setup --> Ticket Routing Rules): the rule only applies when the filter is valid
  • Label Print Rules (POS --> System Setup --> Kitchen Setup --> Label Print Rules): the rule only prints labels when the filter is valid



How to see where a context filter is used

Open the context filter and click the Usage tab. It lists everything that uses this filter - items, modifier sets, comps, terminal screen tabs and more. Click a name to open it.

The Usage tab of a context filter, listing the gift card type, items, profit center, shortcut action and terminal screen tabs that use it

Note: A context filter that is still in use can't be deleted. Take it off everything on the Usage tab first.
